Description

TECHNİCAL SPECİFİCATİONS

  • Bending Speed :  6-12 Rpm/min
  • Max. Bending Moment: 600 Nm
  • Power : 1.1 KW
  • Voltage : 220 V 50-60 HZ
  • Operation Type : Manuel and Automatic
  • Stand High : 85 cm.
  • Electromechanic pedal control
  • The bending switch is direction controlled
  • Emergency stop button
  • Bending angle settings can be adjusted from the holes on the bending flanges
  • Stirrup,bent bar and hook can be easily bended
 Code   DİMENSİONS
 L (mm.)    H (mm.)    D(mm.) (mm.)    Weight (Ad/Pcs)
 17 00 22B  525  350  430  90    1



 BENDİNG CAPACİTY
 45 Kg/mm2   65 Kg/mm2   85 Kg/mm2
 Ø 22×1  Ø 20×1  Ø 16×1
 Ø 16×1  Ø 16×1  Ø 12×2
 Ø 14×2  Ø 14×2  Ø 10×2
 Ø 12×3  Ø 12×2  Ø 8×4
 Ø 8×5  Ø 8×5  Ø 6×5
