TECHNİCAL SPECİFİCATİONS

  • Bending speed : 6 Rpm/min
  • Power : 4 KW
  • Voltage :380 V-400 V 50-60 HZ
  • Operation Type : Manuel and Automatic
  • Electromechanic pedal control
  • The bending switch is direction controlled
  • Different radius of pulley wheels to bend intended radius
  • Emergency stop button
  • Bending angle settings can be adjusted from the holes on the bending flanges
  • Stirrup, bent bar and hook can easily bended
  • Pin holed and adjusting slotted
  • With the help of the bending flanges and the adjusting slots it is easy make bent bar at the first try
  • Bending angle bar can be assembled by adjusting slots
 Code   DİMENSİONS
 L (mm.)    H (mm.)    D(mm.)    Weight (Ad/Pcs)
 17 00 52B  1050  930  850  520  1



 BENDİNG CAPACİTY
 45 Kg/mm2   65 Kg/mm2   85 Kg/mm2
 Ø 52×1  Ø 45×1  Ø 36×1
 Ø 32×2  Ø 30×2  Ø 24×2
 Ø 24×3  Ø 24×3  Ø 20×3
 Ø 20×4  Ø 20×4  Ø 18×4
 Ø 18×5  Ø 16×5  Ø 14×5



Three different bending angles
Adjustable bending by using studs
Automatic or manuel operation
Clockwise or counterclockwise rotation
