TECHNİCAL SPECİFİCATİONS
- Bending speed : 6 Rpm/min
- Power : 4 KW
- Voltage :380 V-400 V 50-60 HZ
- Operation Type : Manuel and Automatic
- Electromechanic pedal control
- The bending switch is direction controlled
- Different radius of pulley wheels to bend intended radius
- Emergency stop button
- Bending angle settings can be adjusted from the holes on the bending flanges
- Stirrup, bent bar and hook can easily bended
- Pin holed and adjusting slotted
- With the help of the bending flanges and the adjusting slots it is easy make bent bar at the first try
- Bending angle bar can be assembled by adjusting slots
| Code | DİMENSİONS |  |
|||
| L (mm.) | H (mm.) | D(mm.) | Weight (Ad/Pcs) | ||
| 17 00 45B | 105 | 930 | 850 | 510 | 1 |
| BENDİNG CAPACİTY | ||
| 45 Kg/mm2 | 65 Kg/mm2 | 85 Kg/mm2 |
| Ø 45×1 | Ø 40×1 | Ø 36×1 |
| Ø 30×2 | Ø 28×2 | Ø 24×2 |
| Ø 24×3 | Ø 22×3 | Ø 20×3 |
| Ø 20×4 | Ø 18×4 | Ø 14×4 |
| Ø 16×5 | Ø 14×5 | Ø 12×5 |
Three different bending angles
Adjustable bending by using studs
Automatic or manuel operation
Clockwise or counterclockwise rotation
